Lazer Rust Removal Machine

Laser cleaning machine mainly uses the laser beam to clean the surface of the workpiece adhesion, applicable to a wide range, easy to automatically control. It has the characteristics of non-abrasive, non-contact, non-thermal effect and suitable for objects of various materials. It can clean rust, oil, oxides, oxidation skin from welding, etc. It can solve the problems that cannot be solved by using traditional cleaning methods.
Product Model: ST-FC1000H/ST-FC1500H/ST-FC2000H
Laser power: 1000W/1500W/2000W
Working area: 170*170mm/250*250mm/300*300mm

Details       Product Parameters       Samples       Video

laser surface cleaning machine features-Suntop

Features of lazer rust removal machine

1. Flexible and easy to operate, can meet the multi-angle, precise location, precise size selective cleaning.

2. Non-contact cleaning, no damage to the substrate of the parts.

3. without using any chemicals, no cleaning agent residue, will not cause damage to the object surface and cause secondary pollution.

4. simple operation, handheld or with a robot to achieve automated cleaning, laser cleaning system stability, almost no maintenance. 3.

5. laser cleaning system is stable, can work continuously and steadily for a long time, almost maintenance-free.

Details of lazer rust removal machine

1. Laser cleaning head

Light weight only 0.7KG, flexible and convenient to clean metal parts of any shape, with a wide cleaning width, up to 300mm. Equipped with a safety monitoring system.

2. Operation interface

Advanced resistive touch screen with higher sensitivity, intelligent control, supports multiple languages (English, Spanish, German, Italian, French, Russian, Turkish, etc.)

3. Laser source

We use a customized 45um core diameter cleaning fiber laser with a lifespan of 100,000 hours and maintenance-free.

4. Water chiller

Double circulating water cooling makes the laser source and cleaning head cool better, and the temperature control sensor adopts imported brands.

5. Cleaning connection fiber

The cable distance from the laser cleaning head to the machine is 10 meters, and there is no need to move the machine when laser welding the workpiece.

6. Wide range of cleaning

The maximum cleaning area is 300*300mm, and the efficiency is high.

Lazer rust removal machine details-Suntop

Advantages of lazer rust removal machine

1. Wide application range: Laser cleaning can remove various types of pollutants on the surface of various materials, and achieve cleanliness that cannot be achieved in conventional cleaning. And you can selectively clean the surface of the material on the surface of the material without damaging the surface of the material.

2. Safety operation: It has multiple safety alarm functions, high safety, and absolute safety during the work of operators.

3. Good cleaning effect: No grinding and non -contact, no heat effect, will not produce mechanical force on the cleaned object, and will not cause damage to the surface of the cleaned object.

4. Green and Environmental Protection: There is no need to use any chemical agent and cleaning solution. The cleaning waste is basically solid powder. It is small, easy to store, recyclable, photochemical reaction, and no pollution.

5. Low cost: The initial investment is high, but it can be used for a long time. The service life is 10 years. The operating cost is low, fast, high efficiency, saving time, and can get investment returns soon.

Cleaning ability (only for reference)

Cleaning surface




Floating embroidery (20um)




Paint (120um)




Rusting (100um)




Lazer rust removal machine safety features

ST-FC1000H/1500H/2000H is a Class IV laser system and routine precautions are required for the safe operation of the equipment.

Built-in features include:

● Key switch control of laser source and Emergency-stop button ensure deliberate operation.

● Fiber laser interlock verifies integrity of laser delivery to the cleaning gun.

● Laser clean gun trigger, enable and then fire, for intentional operation(Double pulling the trigger before the light comes out).

Lazer rust removal machine application

Application materials

Suitable for removing resin, paint, oil stains, stains, dirt, rust, coatings, etc. from the surface of objects.

Application industry

Widely used in automobile manufacturing, mould, cultural relic restoration, aerospace, shipbuilding, 3C electronics, medical equipment, rail transit, steel manufacturing, military equipment, various steel, iron, aluminum materials and other industries.

Parameters of lazer rust removal machine









Power consumption




Max. cleaning width




Laser wavelength


Operation mode


Power adjustment range (%)

10-100 (Gradient adjustable)

Cleaning head weight


Delivery cable length

10M (can be customized)

Input power

220V±10% 50-60HZ

Cooling system

Water Cooled with automatic pumping function

Machine weight




Machine size



Lazer rust removal machine samples-Suntop
