Laser Rust Removal Machine

Laser Rust Removal Machine is a kind of equipment for removing rust by using laser technology, which has the advantages of high rust removal efficiency, easy operation, and no need of chemical agent, etc., which can greatly improve the working efficiency and reduce the production cost. It can deal with rust and corrosion problems on various metal surfaces, and can also be used to clean surfaces such as paints and coatings.
Product Model: ST-FC1500H/ST-FC2000H/ST-FC3000H
Laser power: 1500W/2000W/3000W
Working area: 0-300*300mm
Availability:
Quantity:

Details        Product Parameters        Samples       Video

Laser Rust Removal Machine features-Suntop


Laser Rust Removal Machine is a kind of advanced equipment specialized in removing oxides, coatings and dirt from metal surfaces. The equipment uses a high-energy laser beam to irradiate on the surface to be cleaned, and through the instantaneous high temperature effect, the oxides and dirt are directly vaporized or evaporated, thus realizing a fast and efficient rust removal and cleaning process.


Laser Rust Removal Machine adopts non-contact cleaning, which does not damage the metal surface and maintains the original quality and appearance of the workpiece. Compared with traditional chemical cleaning or mechanical grinding methods, the laser rust remover has the advantages of easy operation, fast cleaning, no chemical emission and no damage. The equipment is suitable for different fields such as metal processing industry, automobile repair industry, ship repair field and cultural relics protection, etc. It can effectively improve the production efficiency, reduce the cost of cleaning, and is suitable for workpieces of various complex shapes and materials.


Laser Rust Removal Machine pictures-Suntop


Product Features of Laser Rust Removal Machine


1. Integrated design, reasonable structure, dustproof, good heat dissipation, effectively extending the service life of machine parts.

2. The handheld cleaning head is small in size and light in weight, and can be operated manually or cooperated with a robot for automatic cleaning. It is especially suitable for cleaning special-shaped surfaces of large products that are difficult to move.

3. Intelligent control system with clear and concise interface and easy operation. Various parameters can be set to control the laser.

4. 10 meters of original optical cable and large universal casters, which can be moved left and right, making it easy to clean objects that are difficult to move.

5. Built-in cold water design avoids wire constraints, adapts to more working conditions and places, and has good dust-proof and anti-condensation effects.

6. It has multiple safety alarm functions and is highly safe, ensuring the absolute safety of operators when working.


Product Configuration of Laser Rust Removal Machine


Laser Rust Removal Machine Laser Generator-Suntop



Famous Fiber Laser Generator

We use the customized 45um core diameter cleaning version fiber lasers with high photoelectric conversion, guaranteed laser power for better cleaning results, and a 100,000 hour, maintenance-free life.



Laser Rust Removal Machine touch screen-Suntop



Interactive touch screen control system

Advanced resistive touch screen with higher sensitivity and intelligent control, supports multiple languages (English, Spanish, German, Italian, French, Russian, Turkish, etc.)


Laser Rust Removal Machine water chiller-Suntop



Industrial water chiller

The industrial water cooler ensures heat dissipation of the core optical path components, double circulation water cooling for better cooling of the laser source and cleaning head, temperature control sensor using imported brands. It can also extend the service life of the laser cleaner.


Laser Rust Removal Machine Cleaning connection fiber-Suntop



Cleaning connection fiber

The cable distance from the laser cleaning head to the machine is 10 meters, and there is no need to move the machine when laser welding the workpiece.



Laser Rust Removal Machine cleaning head-Suntop

Laser cleaning head

The Laser cleaning head is ergonomically designed to be small, comfortable to hold and easy to control and operate. The handheld head is easy to hold and can be used for long periods of time and can be operated at any angle, making cleaning more convenient and flexible.

Features:

● High cleaning cleanliness, big welding width up to 300mm

● Precise positioning and cleaning, weight only 0.7KG, easy to hand it.

● Non-contact material when cleaning that can protect the material.

● Effectively remove micron-sized particles.

● Environment friendly, no consumables.




Laser Rust Removal Machine protect user safety-Suntop




Multiple insurance to protect user safety

- Knob safety lock,open when in use, not afraid of misoperation.

- Single button to start laser, double-click the button to start laser, two modes can be selected.



Product Advantages of Laser Rust Removal Machine


1. Real-time monitoring: Real-time monitoring of the cleaning process and can achieve location-specific and size-specific cleaning.

2. Maintenance free: Low running costs, the laser cleaning system is stable and requires little maintenance.

3. Environmentally friendly: There is no chemical pollution, almost no damage to the material surface.

4. High Efficiency: Automatic operation, stable output, high efficiency, no chemical cleaner needed, no consumables.

5. Host control system: The operation panel is easy to understand (system support: English, Turkish, Italian, Spanish, German, French, Russian), easy to operate, and can be configured with various parameters to control both the laser and the ammeter.


Cleaning ability (only for reference)


Power

Material

Cleaning speed

Effective   beam/cleaning range

Depth of cleaning

Cleaning   efficiency (cubic/H)

1500W

Floating   embroidery

50mm/S

150mm

20um

15

Paint

50mm/S

150mm

100um

6

Rusting

50mm/S

150mm

120um

4

2000W

Floating   embroidery

50mm/S

300mm

20um

20

Paint

50mm/S

300mm

100um

8

Rusting

50mm/S

300mm

120um

5

3000W

Floating   embroidery

50mm/S

300mm

20um

30

Paint

50mm/S

300mm

100um

14

Rusting

50mm/S

300mm

120um

9


Product Specification of Laser Rust Removal Machine


Model

ST-FC1500H

ST-FC2000H

ST-FC3000H

Power

1500W

2000W

3000W

Power   consumption

3000W

4500W

6000W

Max.   cleaning width

170*170mm

250*250mm

300*300mm

Laser   wavelength

1064nm

Operation   mode

Handheld

Power   adjustment range (%)

10-100   (Gradient adjustable)

Cleaning   head weight

0.7Kg

Delivery   cable length

10M   (can be customized)

Input   power

220V±10%   50-60HZ

Cooling   system

Water   Cooled with automatic pumping function

Machine   weight

140KG

220KG

220KG

Machine   size

935*720*1248mm

1500*880*1160mm


Laser Rust Removal Machine samples-Suntop


Application materials of Laser Rust Removal Machine


Suitable for removing resin, paint, oil stains, stains, dirt, rust, coatings, etc. from the surface of objects.


Application industry of Laser Rust Removal Machine


Widely used in various industries such as the ship industry, automobile accessories, precision parts, molds, high -end machine tools, military equipment, building exterior walls, cultural relics protection, track, environmental protection industry and other industries.


Quality assurance


1.. Every production process has a special person to test to ensure quality

2. Have professional engineers to check the quality

3. All products have passed CE, FDA, ISO9001 and other certifications

4. Suntop Laser Cleaning Machine is subjected to strict tests and continuous 24-hour laser beam output before leaving our factory to ensure 100% machine stability


Packing List:


Wooden case, 1pcs/case

Water-cooled base unit

10m laser welding gun cable (15 meters cable length optional)

Laser safety glasses*1

Protective lens*5

USB*1

Laser inspection report


FAQ


1. How can i place an order?
Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time.
For further discussion, it is better to contact us with WhatsApp / WeChat / email / phone, in case of any delays.
2. What kind of display we provide?
We have laser marking machine / laser welding machine / laser cutting machine / laser cleaning / CO2 laser cutting and engraving machine / laser accessories for you choose.
3. How about the warranty?
We have 2 years warranty and lifelong maintenance
4. What is your terms of delivery?
We accept EXW, FOB, CFR, CIF, DDU, DDP, etc. You can choose the one which is the most convenient or cost effective for you.
