Fiber Laser Rust Removal Machine

Laser cleaning machine is a green, energy-saving and efficient industrial tool that uses high-energy-density laser beams to irradiate the surface of the workpiece to instantly evaporate or peel off dirt, rust spots or coatings on the surface. In practical applications, it can quickly remove paint, Rust removal, removal of oxides, oil stains, oil stains and product residues, restoration and preservation of historical relics, etc.
Product Model: ST-FC1500H/ST-FC2000H/ST-FC3000H
Laser power: 1500W/2000W/3000W
Working area: 200*200mm/250*250mm/300*300mm
Availability:
Quantity:

Details         Product Parameters         Samples        Video

fiber laser rust removal features-Suntop


Features of fiber laser rust removal


1. Non-contact cleaning, which is precise, can selectively operate on precise positions and sizes.

2. The hand-held cleaning head is small and light, and can be operated by hand or automatically cleaned with a robot, making it especially suitable for cleaning the special-shaped surface of large products that are inconvenient to move.

3. The intelligent control system has a clear and concise interface, making it easy to operate, and various parameters can be set to control the laser.

4. The 10-meter original optical cable and universal big casters allow for left and right movement, making it easy to clean objects that are not easy to move.

5. The built-in cold water design avoids wire binding, making it adaptable to more working conditions and places, and it has good dust and condensation prevention effects.

6. It has multiple safety alarm functions and is highly safe, ensuring the absolute safety of operators when working.



Details of fiber laser rust removal


1. Laser cleaning head

Weighing only 0.7kg, it is compact and convenient to clean any shape of metal parts with a wide cleaning width of up to 300mm and equipped with a safety monitoring system.

2.Intelligent operation interface

Advanced resistive touch screen with higher sensitivity and intelligent control, supporting multiple languages (English, Spanish, German, Italian, French, Russian, Turkish, etc.)

3. Laser source

We use a custom 45UM core diameter clean fiber laser with a lifetime of 100,000 hours and no maintenance included.

4. Water Cooler

Double circulation water cooling can make the laser source and cleaning head more cool, temperature control sensor using imported brands.

5. Cleaning connection fiber

The cable distance from the laser cleaning head to the machine is 10 meters, so there is no need to move the machine when laser welding workpiece.

6.Large cleaning area

The maximum cleaning area is 300*300mm with high efficiency.

fiber laser rust removal details-Suntop



Advantages of fiber laser rust removal


1. High efficiency: Laser cleaning is fast and can quickly and thoroughly remove dirt and coatings on the surface of objects, improving cleaning efficiency.

2. Thorough cleaning: Laser cleaning can remove various dirt such as particles, oil stains and oxide layers on the surface of the object, achieving thorough cleaning while keeping the surface of the object intact.

3. Precise control: Parameters such as laser energy, scanning speed and focal length can be accurately adjusted to achieve precise control of cleaning depth and range, adapting to the cleaning needs of various materials and surfaces.

4. Environmental protection and energy saving: There is no need to use chemicals and cleaning agents during the laser cleaning process, which reduces environmental pollution and saves water and energy consumption.

5. Long-term stability: Laser cleaning equipment has long-term stable working performance and high reliability, and can meet the needs of continuous and long-term cleaning.



Cleaning ability (only for reference)


Power/W

Material

Cleaning speed

Effective beam/cleaning range

Depth of cleaning

Cleaning efficiency (cu.m./H)

1500

floating rust

50mm/S

150mm

20um

15

Paint

50mm/S

150mm

100um

6

Rusting

50mm/S

150mm

120um

4

2000

floating rust

50mm/S

300mm

20um

20

Paint

50mm/S

300mm

100um

8

Rusting

50mm/S

300mm

120um

5

3000

floating rust

50mm/S

300mm

20um

30

Paint

50mm/S

300mm

100um

14

Rusting

50mm/S

300mm

120um

9



Handheld cleaning head

fiber laser rust removal head-Suntop


● High cleaning cleanliness, big welding width up to 300mm.

● Precise positioning and cleaning, weight only 0.7KG, easy to hand it.

● Non-contact material when cleaning that can protect the material.

● Effectively remove micron-sized particles.

● Environment friendly, no consumables.



Safety features


ST-FLC1500H/2000H/3000H is a Class IV laser system and routine precautions are required for the safe operation of the equipment.

Built-in features include:

● Key switch control of laser source and Emergency-stop button ensure deliberate operation.

● Fiber laser interlock verifies integrity of laser delivery to the cleaning gun.

● Laser clean gun trigger, enable and then fire, for intentional operation(Double pulling the trigger before the light comes out).



Application materials


Suitable for removing resin, paint, oil stains, stains, dirt, rust, coatings, etc. from the surface of objects.



Application industry


It is widely used in various industries such as the ship industry, automobile accessories, precision parts, molds, high -end machine tools, military equipment, building exterior walls, cultural relics protection, track, environmental protection industry and other industries.



Parameters of fiber laser rust removal


Model

ST-FLC1500H

ST-FLC2000H

ST-FLC3000H

Power

1500W

2000W

3000W

Laser wavelength

1064nm

Operation mode

Handheld

Power adjustment range (%)

10-100 (Gradient adjustable)

Cleaning head weight

0.7Kg

Delivery cable length

10M (can be customized)

Cooling system

Water Cooled with automatic pumping function

Input power

220V±10% 50-60HZ

380V±10% 50-60HZ

Power consumption

4500W

6000W

8000W

Max. cleaning width

200*200mm

250*250mm

300*300mm

Machine weight

120KG

200KG

220KG

Machine size

935*720*1248mm

1500*880*1160mm




fiber laser rust removal samples-Suntop
