Newly Upgraded Distance Sensing Handheld Laser Marker

Share to:

Handheld Rechargeable Laser Marking Machine with Distance Sensing & Protective Cover

This rechargeable handheld laser marking machine adopts wireless battery-powered design, equipped with intelligent distance sensing module and safety protective cover to avoid accidental laser radiation during operation. Compact and easy to carry, the portable laser marker realizes stable permanent engraving on metals, plastics materials, perfectly suited for outdoor field marking, workshop batch coding, aftermarket part engraving and mobile customized marking scenarios, effectively improving operation safety and construction flexibility compared with traditional wired handheld laser marking equipment.
※ Product Model: ST-FL20H/ST-FL30H/ST-FL50H
※ Laser power: 20W/30W/50W
※ Working area: 70*70mm/110*110mm (optional)

Availability:

Quantity:



Inquire PDF Export

This rechargeable handheld laser marking machine is equipped with intelligent distance sensing and a safety guard. Powered by a wireless lithium-ion battery, it eliminates the need for power cords. Compact and lightweight, it can be easily operated by a single person. The distance-sensing feature automatically adjusts the marking distance to prevent blurred engravings caused by focal length deviations. The included protective cover effectively blocks laser scattering, significantly enhancing on-site safety, and makes the device suitable for flexible use in various scenarios, including workshops and outdoor on-site marking.

The device can produce permanent, clear markings on a variety of surfaces, including stainless steel, iron, aluminum alloy, plastic, and hardware components. The markings are scratch-resistant and fade-proof, making them ideal for applications such as part numbering, hardware logos, product traceability codes, and custom engraving. Compared to traditional plug-in handheld marking devices, this model offers superior battery life and portability, free from power outlet constraints, making it ideal for processing small-batch orders and on-site marking services.

The unit features an internal heat dissipation channel design, ensuring it remains cool even during prolonged continuous operation. It operates stably with a low failure rate and is easy to use, requiring no complex setup. Both small and medium-sized enterprises and processing shops can quickly deploy it for mass production.

Product Features

Concealed Field Lens Design

Concealed Field Lens Design

The upgraded concealed structure prevents accidental collision and contact, providing comprehensive protection for the field lens and reducing daily wear and tear.

Ergonomic Handheld Head

Designed with an ergonomic grip and anti-slip rubber surface. Weighs merely 0.8kg with a compact size, enabling fatigue-free single-hand operation for long working hours.

Handheld head

Smart Touch Screen

Intelligent Touch Screen

Independent smart touch screen supports direct content editing and parameter adjustment. PC-free operation simplifies the marking process and improves overall work efficiency.

External Dual USB Ports

Equipped with dual USB interfaces to support multiple file format import and data reading. Convenient for quick content replacement and customized marking tasks.

External Dual USB Port

Dual Power System

Flexible Dual Power System

Comes with a built-in high-capacity rechargeable battery for wireless outdoor use. It also supports plug-in power supply to meet continuous long-time industrial processing demands.

Efficient Built-in Air Cooling System

Adopts optimized air cooling structure to accelerate heat dissipation. Stable temperature control protects core optical parts and effectively prolongs the machine’s service lifespan.

Built-in air cooling

Advantages of Handheld Laser Marking

• Built-in rechargeable battery for cordless operation

No external power cable restriction, free to shift marking positions on-site, suitable for outdoor processing and mobile workpiece marking.

• Intelligent distance sensing positioning

Auto identify marking distance, automatically adjust focal length, effectively avoid unclear marking caused by uneven workpiece surface.

• Equipped with full protective safety cover

Blocks laser stray light and splashes, protects operator eyes and body, meets industrial safety operation standards.

• Compact handheld lightweight design

Easy single-hand holding, flexible for irregular, curved and large unmovable parts marking.

• Optional built-in LED lighting & cooling fan

LED auxiliary lamp works for dim working environment; cooling fan lowers core temperature to prolong continuous working hours.

• Wide compatible marking materials

Stable permanent marking on stainless steel, aluminum, plastic, ABS, coated hardware and most common industrial materials.

• Clear permanent laser engraving effect

Marking content wear-resistant, not easy to fade, no ink consumption, low later operating cost vs ink jet printer.

• Simple parameter setting & easy operation

Intuitive control panel, no complex professional training required for new operators to get started quickly.

FAQ

1. How can i place an order?
Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time.
For further discussion, it is better to contact us with WhatsApp / WeChat / email / phone, in case of any delays.

2. What kind of display we provide?
We have laser marking machine / laser welding machine / laser cutting machine / laser cleaning / CO2 laser cutting and engraving machine / laser accessories for you choose.

3. How about the warranty?
We have 2 years warranty and lifelong maintenance

4. What is your terms of delivery?
We accept EXW, FOB, CFR, CIF, DDU, DDP, etc. You can choose the one which is the most convenient or cost effective for you.

5. Is this laser marker completely cordless? How long is the battery working time?

Yes, it adopts built-in rechargeable lithium battery for full cordless use without external power cord. Fully charged battery supports 3–8 hours continuous marking depending on laser power; spare batteries are optional for long-time outdoor jobs.

6. How long does full charging take? Can I charge while working?

Full charging needs around 3–4 hours. Charging during operation is available, but better fully charge beforehand to extend battery service life.

7. What is the function of distance sensing?

The distance sensor automatically detects workpiece height and adjusts laser focus in real time. It solves unfocused, fuzzy marking caused by uneven or curved surfaces.

8. What’s the use of the matched protective cover?

The enclosed protective cover blocks laser stray light and metal spatter, effectively protecting operator’s eyes and skin, complying with industrial safety specifications.

9. Can it mark on oversized unmovable equipment?

Handheld portable design allows moving the machine toward fixed big workpieces like machinery, pipes and construction hardware.

10. Is professional training required for new users?

No complicated training needed. The machine has simple touch/button control; we provide operation manual and operation video for quick start.

Technical Specifications Table
Laser	Fiber Laser Generator (Second Generation)	Positioning method	Red light positioning and focusing
The output power	depends on the purchased model	Number of lines of engraved characters	Any row within the effective marking range
Marking range	70×70mm / 100×100mm (optional)	Printing speed	800 characters (related to material and printing content)
Deflection mirror	High-precision dual dimensional scanning system	Font	Standard character libraries for Chinese, English, numbers, traditional Chinese, etc.
Laser wavelength	1064nm	File format	BMP, DXF, PNG、JPEG、PLT、XLSX
Focus lens	1300mm	Barcode	CODE 2-Of-5 Interleaved、CODE39、CODE128、QR、Codabar、CODE93、UPC-A、UPC-E、EAN-14、ITF-14、EAN128 and so on
Marking speed	≤7000mm/s	Power supply	110V/220V AC Lithium battery pack: 20W/30W: 216Wh 50W: 324Wh
Master control	Integrated motherboard, 8-inch capacitor fully integrated screen	Overall power consumption	145-250W
Operating system	Linux system	Operating temperature of the whole machine	0-40℃
Marking and engraving type	Dot matrix and vector all-in-one machine	The whole machine weight	20W/30W: 6-6.8KG, 50W: 8-8.8KG
Line width	0.03mm	Packaging box specifications	20W/30W: 525 × 423 × 310 mm 50W: 525 × 420 × 340mm
Repeat positioning accuracy	0.01mm	Packaging + machine weight	20W/30W: 8-10KG, 50W: 10-12KG
