fiber laser engraver for firearms

The firearm fiber laser engraving machine is a piece of equipment specially used for marking and engraving on firearms. It uses fiber laser as an engraving tool to directly engrave text, patterns or logos on the surface of the firearm through a high-energy laser beam.
Product Model: ST-FL20B/ST-FL30B/ST-FL50B/ST-FL100B
Laser power: 20W/30W/50W/100W
Working area: 110*110mm-600*600mm
Availability:
Quantity:

Details        Product Parameters        Samples       Video

fiber laser engraver for firearms features-Suntop


Features of fiber laser engraver for firearms

1. Adopting imported fiber laser, high beam quality, small focused spot, ultra-fine marking, high clarity.

2. Adopting digital high-speed scanning galvanometer, high processing precision and stable performance.

3. integrating drawing editing, hardware setting and marking control in one, fast marking speed and better effect.

4. the electro-optical conversion efficiency is very high, reaching more than 30%, the use of low cost, power saving and energy saving.

5. Scanning head built-in red light for previewing the marking position, easier and more accurate to find the laser focus.


Details of fiber laser engraver for firearms

1. Laser source

Adopt famous brand MAX, Raycus, JPT laser, with stable light output, delicate spot and strong focusing effect.

2. High-speed oscillator

High precision laser scanning vibrating lens, fast and clear, high stability, can realize high speed marking, high precision.

3. F-theta lens

Intelligent F-theta lens, the fiber laser beam is focused to the workpiece surface through the lens, with sufficient energy.

4. Industrial control computer

With high anti-magnetic, dustproof, shockproof and strong anti-interference ability, can work continuously for a long time

5. Control panel

BJJCZ brand original EZCAD control system, high stability, simple operation and good performance.


fiber laser engraver for firearms details-Suntop


Advantages of fiber laser engraver for firearms

● High precision: It has very high precision and control capabilities, and can accurately engrave detailed text, patterns and logos on the surface of the firearm. It can achieve high-precision engraving effects such as tiny fonts, complex patterns and delicate lines.

● Permanent: Laser engraving can permanently engrave marks on the surface of the firearm and will not fade, wear or be affected by the environment. This makes the marking durable and traceable, helping to improve the safety and anti-counterfeiting of the firearm.

● High efficiency: With the ability of high-speed engraving, it can complete a large number of firearm engraving tasks in a short time. This increases productivity and reduces waiting times.

● Non-contact engraving: Engraving is done in a non-contact way, without direct contact with the firearm surface. This reduces mechanical wear while avoiding the risk of potential damage to the firearm.

● Flexibility: Can be customized and adjusted as needed to accommodate firearms of different sizes, shapes and materials. It can engrave on a variety of materials, including metal, plastic, leather, and more.


Application materials of fiber laser engraver for firearms

Suitable for working with most metal marking applications such as Gold, Silver, Stainless Steel, Brass, Aluminium, Steel, Iron Titanium etc, and can also mark on many nonmetal materials,such as ABS, Nylon, PES, PVC etc.


Application industry of fiber laser engraver for firearms

Metals, alloy, oxide, ABS, epoxy resin, printing ink, etc, which are widely applying for electronics, jewelry, automobiles, communication products, phone keys, plastic translucent keys, jewelry products, key chain, electronic components, integrated circuits (IC), electrical appliances, buckles cookware, stainless steel products and other industries.


Parameters of fiber laser engraver for firearms

Model

ST-FL20B/ST-FL30B/ST-FL50B/ST-FL100B

Laser power

20W/30W/50W/100W   (optional)

Marking area

110*110mm-600*600mm   (depend on the actual laser power)

Laser wavelength

1064nm

Working accuracy

±0.002mm

Marking Depth

0-0.5mm

Minimum font for   marking

0.15mm

Minimum character

0.2mm

Marking speed

0-7000mm/s

Operating system

Win7 and Win10/32   bit and 64 bit

Laser source

MAX Brand(Raycus can be choose)

Repetition   frequency

20-100KHz

Cooling mode

Air Cooling

Graphic format   supported

AI, PLT, DXF, BMP,   DST, DWG, DXP

Environmental   requirements

Temperature:   10-35℃, Humidity: 5-75%

Working voltage

220V±10% 50/60 Hz

Applicable material

All metal (Stainless   steel, Carbon steel, Brass,etc.) and some plastic(ABS, PVC,PES, ETC.)

Optional   Accessories to Purchase

D80 Rotating Shaft/   D57 Small Chuck/2D Table (X.Y direction)/ Cutting Fixture

Net weight/gross   weight (KG)

120KG / 150KG

Machine dimension

860*760*1130mm   (L*W*H)



fiber laser engraver for firearms samples-Suntop
