Fiber Laser Cleaning Machine

Laser cleaning technology is to irradiate the surface of the workpiece with a high power density laser beam, so that the surface dirt, rust or coating instantly evaporate or flake off, so as to achieve the purpose of cleaning. It is a representative high-tech product for surface treatment, easy to install, operate and automate. The operation is very simple, no chemicals, no media, no dust, no water, and can be cleaned by plugging in electricity.
Product Model: ST-FC1000H/ST-FC1500H/ST-FC2000H
Laser power: 1000W/1500W/2000W
Working area: 170*170mm/250*250mm/300*300mm
Availability:
Quantity:

Details       Product Parameters       Samples       Video

Fiber laser cleaning machine features-Suntop

Features of fiber laser cleaning machine

1. Integrated design, reasonable structure, dustproof, good heat dissipation, effectively prolonging the service life of machine parts.

2. Equipped with 10 meters of original optical fiber cable, it can be moved and operated, and can clean the parts that are not easy to reach.

3. The lightweight design of the hand-held cleaning head weighs only 0.7kg, making it easy to handle.

4. By adjusting the laser process parameters, the pollutants can be effectively removed without damaging the surface of the substrate, making the surface look like new again.

5. It can be transmitted through optical fiber and cooperate with manipulators and robots to conveniently realize long-distance operation, and can clean parts that are difficult to reach by traditional methods. This can ensure the safety of personnel in some dangerous places.


Details of fiber laser cleaning machine

1. Laser cleaning head

Light weight only 0.7KG, flexible and convenient to clean metal parts of any shape, with a wide cleaning width, up to 300mm. Equipped with a safety monitoring system.

2. Operation interface

Advanced resistive touch screen with higher sensitivity, intelligent control, supports multiple languages (English, Spanish, German, Italian, French, Russian, Turkish, etc.)

3. Laser source

We use a customized 45um core diameter cleaning fiber laser with a lifespan of 100,000 hours and maintenance-free.

4. Water chiller

Double circulating water cooling makes the laser source and cleaning head cool better, and the temperature control sensor adopts imported brands.

5. Cleaning connection fiber

The cable distance from the laser cleaning head to the machine is 10 meters, and there is no need to move the machine when laser welding the workpiece.

6. Wide range of cleaning

The maximum cleaning area is 300*300mm, and the efficiency is high.

Fiber laser cleaning machine details-Suntop


Advantages of fiber laser cleaning machine

1. Wide range of applications: Laser cleaning can remove various types of pollutants on the surface of various materials, achieving a cleanliness that cannot be achieved by conventional cleaning. Moreover, the pollutants on the surface of the material can be selectively cleaned without damaging the surface of the material.

2. Operational safety: It has multiple safety alarm functions, high safety, and guarantees the absolute safety of operators during work.

3. Good cleaning effect: no grinding and non-contact, no thermal effect, no mechanical force on the object to be cleaned, and no damage to the surface of the object to be cleaned.

4. Environmental protection: No need to use any chemicals and cleaning fluids, the waste after cleaning is basically solid powder, small in size, easy to store, recyclable, no photochemical reaction, and no pollution.

5. Low cost: The initial investment is high, but it can be used stably for a long time, with a service life of up to 10 years, low operating cost, fast speed, high efficiency, time-saving, and a quick return on investment.


Cleaning ability (only for reference)

Cleaning surface

1000W

1500W

2000W

Floating embroidery (20um)

10m⊃3;/h

15m⊃3;/h

20m⊃3;/h

Paint (120um)

4m⊃3;/h

6m⊃3;/h

8m⊃3;/h

Rusting (100um)

2.5m⊃3;/h

4m⊃3;/h

5m⊃3;/h


Compared to traditional cleaning

Project

Laser cleaning

Chemical cleaning

Mechanical cleaning

Ultrasonic cleaning

Cleaning method

Non-contact (laser)

Contact (chemical cleaner)

Contact (mechanical)

Contact (cleaner)

Workpiece damage

No damage

Damaged

Damaged

Damaged

Cleaning efficiency

High

Low

Low

Middle

cleaning effect

High cleanliness

Uneven

Uneven

High cleanliness (small range)

Cleaning accuracy

High precision (accurate and controllable)

Poor accuracy (uncontrollable)

Average accuracy (uncontrollable)

Unable to specify range cleaning

Environmental friendly

Pollution-free

Polluted

Polluted

Polluted

Cost input

High initial investment (no consumables, maintenance)

Low initial investment (very high cost of consumables)

High initial investment (high labor cost of consumables)

Low initial investment (moderate cost of consumables)

Fiber laser cleaning machine application

Application materials

Suitable for removing resin, paint, oil stains, stains, dirt, rust, coatings, etc. from the surface of objects.


Application industry

It is widely used in various industries such as the ship industry, automobile accessories, precision parts, molds, high -end machine tools, military equipment, building exterior walls, cultural relics protection, track, environmental protection industry and other industries.


Parameters of fiber laser cleaning machinee

Model

ST-FC1000H

ST-FC1500H

ST-FC2000H

Power

1000W

1500W

2000W

Power consumption

3000W

4500W

6000W

Max. cleaning width

170*170mm

250*250mm

300*300mm

Laser wavelength

1064nm

Operation mode

Handheld

Power adjustment range (%)

10-100 (Gradient adjustable)

Cleaning head weight

0.7Kg

Delivery cable length

10M (can be customized)

Input power

220V±10% 50-60HZ

Cooling system

Water Cooled with automatic pumping function

Machine weight

220KG

230KG

280KG

Machine size

935*720*1248mm

1500*880*1160mm


Fiber laser cleaning machine samples-Suntop
