CO2 Laser Engraver

CO2 laser engraving machine using non-contact processing, will not cause mechanical extrusion or mechanical stress on the material, no "knife marks", no harm to the surface of the processing surface, will not deform the material. This machine has the advantages of high beam quality, fast cutting speed and high cutting accuracy. It can carve and cut various non-metal materials, such as jade, crystal, acrylic, wood, plastic, etc.
Product Model: ST-CC6040/ST-CC9060/ST-CC1390
Laser power: 600*400mm/900*600mm/1300*900mm
Working area: 60W/80W/100W/130W/150W/180W/200W (optional)
Availability:
Quantity:

Details       Product Parameters       Samples       Video

CO2 laser engraver features-Suntop

Features of CO2 laser engraver

1. Adopt the third-generation high-intelligence control system, automatic control, high positioning accuracy, smooth forming edge.

2. Imported linear guide rail and high-speed stepping motor and driver, stable performance, high precision, smooth cutting edge without ripples.

3. Using imported lasers and optical devices, the spot quality is good, the output power is stable, and the maintenance cost is low.

4. The honeycomb work surface has high flatness, is not easy to deform, and is durable.

5. Double-head and multi-head cutting systems can be selected according to customer requirements to improve production efficiency, reduce production costs, and support customization.


Details of CO2 laser engraver

1. Adjustable laser head

The aluminum alloy adjustable laser head is lighter than other metal laser heads, which can minimize the inertia error when the laser head moves.  The outer oxide film has a beautiful appearance and is durable and not deformed for a long time.

2. CO2 laser tube

The speed of light is stable, the power is high, the cutting speed is fast, and the quality is good.

Laser tube life is 10,000 hours.

Laser power 60W/80W/100W/130W/150W/200W optional.

3. High precision linear guide

Adopt high-precision high-speed belt drive, long service life.

High speed and stability, low running resistance and low noise.

The incision is precise and the work efficiency is high.

4. Mirrors and lenses

Adopt foreign imported focusing lens and reflector, high efficiency and stability.

The focal length adjustment part makes it easy to find the center of the lens and find the correct focal length.

5. LCD control panel

Which can not only work without computer, but also connect to U disk, USB communication.

Multilingual control panel, convenience of operation control.

6. Stepper motor control system

Digital timing, analog quantum control laser power, small error, high repeatability, maintenance-free.

The possibility of realizing extremely precise positioning is guaranteed, and the mobile positioning mechanism runs smoothly.

Low noise, not easy to heat, safe and reliable.

7. Laser protective cover

When the cover of the machine is opened, the machine stops working to prevent accidental injury to the operator by machinery and lasers. Make sure that the operator will not be hurt by the laser beam and protect the operator's safety.

8. Precision water chiller

CW-5000 water chiller has a temperature display, which can prevent overheating and burning, and prevent the water circulation from being cut off.

9. Collection drawer

Facilitates easy collection and acquisition of cut objects.

It is convenient for cutting waste and flying dust to clean up.

10. Honeycomb workbench

The small holes of the honeycomb workbench have good support performance, firm structure, and will not deform during processing, and small workpieces can be placed on the workbench for processing.

CO2 laser engraver details-Suntop


Advantages of CO2 laser engraver

1. Safe and reliable: Non-contact processing will not cause mechanical extrusion or mechanical stress to the material, will not damage the surface of the workpiece, and will not deform the material.

2. High-speed and fast: It can immediately perform high-speed engraving and cutting according to the pattern output by the computer.

3. Low cost: not limited by the quantity of processing, laser processing is cheaper for small batch processing services.

4. Wide range: carbon dioxide laser can engrave and cut almost any non-metallic material.

5. Energy saving and environmental protection: the diameter of the beam and spot is small, generally less than 0.5mm; the cutting process saves materials and is safe and hygienic.


CO2 laser cutting thickness (only for reference)

Materials type

40W

60W

80W

100W

120W

150W

200W

Wood

3mm

7mm

10mm

12mm

13mm

15mm

18mm

Plywood

2mm

6mm

10mm

12mm

13mm

15mm

18mm

Leather

1mm

3mm

4mm

5mm

6mm

7mm

10mm

Acrylic

2mm

10mm

13mm

15mm

17mm

16mm

20mm

PVC

1mm

3mm

4mm

5mm

6mm

7mm

8mm

Plastic (easy to melt)

1mm

2mm

3mm

4mm

5mm

6mm

8mm

Rubber

2mm

3mm

4mm

5mm

6mm

7mm

10mm

Crystal/Jade/Stone/Marble/Medal

Only for engraving

Clothing(fabric,wool)

2mm

3mm

4mm

5mm

6mm

8mm

10mm

Bamboo Works

1mm

3mm

4mm

5mm

6mm

7mm

10mm

CO2 laser engraver application

Application materials

Suitable for all kinds of non-metallic materials, such as plastic,acrylic, jade, crystal, rubber,leather, organic glass etc.


Application industry

Widely used in craft gifts, furniture, leather clothing, advertising signs, model making, food packaging, pharmaceutical packaging, electronic components, communications, clocks, glasses, printing plate making, shell nameplates and other industries.


Parameters of CO2 laser engraver

Model

ST-CC6040

ST-CC9060

ST-CC1390

Working area

600*400mm

900*600mm

1300*900mm

Laser power

60W/80W/100W/130W/150W/180W/200W (optional)

Laser type

Hermetic and detached Co2 laser tube

Control configuration

DSP

Cooling mode

Water cooling and protection system

Position system

Red dot

Max moving speed

1500mm/s

Laser energy control

1-100℅ set by hand or software

Locating precision

<0.01 mm

Min shaping character

Character: 3*3 mm, letter: 2*2 mm

Worktable

Electric up and down table, with the first layer Honeycomb table and the second Aluminum knife table (Two layers) for different kinds of materials cutting

Resolution ratio

≦4500 dpi

Power supply

AC220±10℅ 50 HZ, AC110±10℅ 50 HZ

System environment

Windows 7/Windows 10, 32bits or 64 bits

Limit switch

Induction metal limit switches for accurate positioning of X and Y positions

Motion control mode

Precision linear guide

Air pressure control

There is a device to adjust the air pressure at the cutting head

Package Inclusion

Software, Video user menu CD Air pump gun, Power cables, USB cables, Water tank, Water Pipe, Smoke Vent-pipe, Air Blow Pipe, exhaust fan, Tools bag

Dimensions(package)

1530*850*800mm

1600*1140*1300mm

2050*1480 *1280mm

Gross weight

150KG

306Kg

420KG
