3D Laser Inner Engraving Machine for Glass

3D crystal internal engraving machine, a high-resolution laser engraving machine with high fidelity and stability of fine processing machines, suitable for fine model engraving and processing centers, gift stores, craft stores, photo printing stores, wedding photography, souvenirs, personalized gift stores, etc.
Product Model: ST-LCE2513/ST-LCE30185/ST-LCE1280/ST-LCE3015/ST-LCE-LA/ST-LCE-LB
Laser power: 3W
Working area: 1300*2500*110/1850*3000*80/800*1200*150/1500*3000*110/1830*2440*80
Availability:
Quantity:

PDF Export

Details       Product Parameters       Samples       Video

3D laser inner engraving machine for glass features-Suntop

Features of 3D laser inner engraving machine for glass

1. Suntop self-developed and designed with the functions of engraving, surface frosting and marking, embossing and glass drilling on the lower surface of glass plate, designed for the innovative processing of art glass.

2. Adopting automatic positioning system, maintenance-free optical path system, high-precision motion control system, modular equipment, simple and convenient maintenance.

3. Adopt high precision linear module to improve assembly precision, imported grinding screw and guide rail to keep high precision and smoothness of machine in high speed operation.

4. Adopting laser self-collimation technology and closed-loop monitoring system, 24-hour continuous operation, "zero-width" splicing technology for image engraving, humanized system control and monitoring operation design, one-touch completion of engraving work, avoiding human operation errors.

5. Equipped with self-developed special software, can support dxf, obj, bmp, jpg and other flat and 3D format data, with good compatibility.


Details of 3D laser inner engraving machine for glass

1. High-quality machine tools

The unique machine tool mechanism adopts self-service design, multiple imported servo motors, imported electrical components, and thickened workbench, which make the machine tool stable and durable.

2. 3D camera

Equipped with self-developed software and 3D camera, it can design delicate and precise human portraits.

3. Japanese servo motor

X and Y axes are equipped with Japanese servo motors with high precision, high speed, high torque, high inertia and stable performance, which ensure the high speed and acceleration of the whole machine.

4. Rack and pinion

Grinding gear technology is adopted to adapt to various use conditions, dustproof, and ensure long-term high-precision movement.


Advantages of 3D laser inner engraving machine for glass

1. Good engraving quality, exquisite and delicate laser engraving effect, traditional glass processing methods can not be compared with it.

2. Wide engraving range, able to meet the needs of personalized engraving customization, with high engraving and marking speed.

3. non-contact processing method, the overall loss of equipment is low, a device can work in the standard environment for more than 10 years.

4. No pollution, no dust, no toxic gas, no water consumption, no chemical materials.

5. Intelligent, simple operation, fast and convenient work, no wearing parts.

6. Suitable for mass production, and support multiple small pieces of glass of different sizes on the table for batch one-time engraving.

3D laser inner engraving machine for glass application

Application materials

Suitable for crystal cube, transparent glass/arcylic and plastic,etc.


Application industry

It is widely used in 2D and 3D crystal photo engraving, artistic photo engraving, personalized crystal gift engraving, batch processing of high-precision crystal products, glass decoration, glass marking, high-grade glass anti-counterfeiting and other fields.


Parameters of 3D laser inner engraving machine for glass

Model

ST-LCE2513

ST-LCE30185

ST-LCE1280

ST-LCE3015

ST-LCE-LA

ST-LCE-LB

Max. engraving size (mm)

1300*2500*110

1850*3000*80

800*1200*150

1500*3000*110

1830*2440*80

Average engraving speed

180000-480000 dots/min

220000-280000 dots/min

Diameter for dots

80-120μm

40-80μm

Mass production function

Mass production (engraving size can be customized)

Laser medium

Laser diode

Laser wavelength

532nm

Cooling system

Air cooling

Working temperature

10-45℃

Power supply

380V/50-60HZ

AC220V or 110V ±10%


3D laser inner engraving machine for glass samples-Suntop
