3d Fiber Laser Marking Machines

3D fiber laser marking machine has the function of three-dimensional curved surface marking, suitable for laser marking of various three-dimensional curved surfaces, no defocus phenomenon, fast speed, high efficiency, high stability, and extremely low operating costs.
Product Model: ST-FL30-3D/ST-FL50-3D/ST-FL60-3D/ST-FL100-3D
Laser power: 30W/50W/60W/100W
Working area: 110*110mm/175*175mm/300*300mm/600*600mm/800*800mm

Details       Product Parameters       Samples       Video

3d fiber laser marking machine features-Suntop

Features of 3d fiber laser marking machine

1. Equipped with professional 3D scanning lens and automatic control system.

2. Adopt advanced digital three-axis dynamic focus technology, fast marking speed, high real-time zoom control and uniform focus spot.

3. Adopting 3D fine marking system software, it can meet various manual engraving needs, such as relief patterns, deep engraving, shade engraving, etc., which improves the three-dimensional sense of details.

4. With three-dimensional surface three-dimensional marking function, it can concentrate fine light spot and symmetrical marking within the relative height standard of 0~60mm size tolerance. Marking irregular products such as curved surfaces, slopes, steps, spheres, cylinders and cones without enlargement.

5. Large processing width, marking range can be adjusted according to the specific processing requirements, and there is no defocus phenomenon during the whole process.

6. Support 3D model import, 2D graphics can be directly wrapped or projected onto the built-in common surface.

Details of 3d fiber laser marking machine

1. Fiber laser source

Raycus / JPT / MAX / IPG brand can be chosen.

2. 3D digital scanning head

Famous brand SINO-GALVO oscilloscope scanning head, high speed and accurate marking.

XYZ three axes, irregular / surface marking, Z axis can be flexible automatic movement.

3. Professional 3D galvanometer

Variable focal length, precise control of focal position, ensure focal size and spot quality to realize the engraving of irregular products.

4. Double red light preview

Help to find the focal distance quickly, no need to use ruler, just check whether the red dots and red lines on the surface of the product to be marked overlap.

3d fiber laser marking machine details-Suntop

Advantages of 3d fiber laser marking machine

1. 3D laser marking machine spot quality is good, marking point is small, suitable for precise and fine marking.

2. Infrared focusing system does not need to measure the focal length, which is more convenient to work.

3. Non-contact processing, no damage to the product, no tool wear, good marking quality.

4. High marking accuracy, clear and permanent, no fading, no falling off, not easy to be imitated and changed.

5. Stable performance of the whole machine, maintenance-free, long service life, can reach more than 100,000 hours.

6. high efficiency of electro-optical conversion, reaching more than 30%, low cost of use, energy saving and power saving.

Functions of 3d fiber laser marking machine

● Overturn the traditional 2D marking mode. It can carve many different 3D shapes, such as: slopes, cylinders, cones, balls, etc. Realize all-round marking.

● The marking software can import graphics exported by mainstream 3D software, and make simple edits to the graphics. Easy to operate.

● Automatically calculate radians and automatically adjust focus. It can mark multi-level large format, three-dimensional surface, plane, etc.

3d fiber laser marking machine application

Application materials

Suitable for working with most metal marking applications such as Gold, Silver, Stainless Steel, Brass, Aluminium, Steel, Iron Titanium etc, and can also mark on many nonmetal materials,such as ABS, Nylon, PES, PVC etc.

Application industry

Suitable for 3C, automotive, electronic instruments, computer parts, industrial bearings, clocks and watches, electronic and communication products, home appliances, hardware tools, molds, wire and cable, food packaging, medical equipment and other industries.

Parameters of 3d fiber laser marking machine

Laser Power










Max Marking Range


Laser Wavelength


Pulse Energy


Repetitive Frequency


Indicator Laser

Red light 655nm/output 1.0 mW

Minimum Line Width


Marking Speed


Operating System

Windows XP/7/8/10

Font Support

Ture type, AUTOCAD Single line font, custom

One-dimensional Barcode


Two-dimensional Barcode

QR/PDF417/Data matrix (ECC200) etc.



Environmental Requirements

Temperature: 10-35℃, Humidity: 5-75%

Spare Parts Come with the Machine

Protective glasses, Metal business card, Foot switch, Hex socket wrench, Power cord

Optional Accessories to Purchase

D80 Rotating Shaft/ D57 Small Chuck/2D Table (X.Y direction)/ Cutting Fixture

Power supply

220V±10%  50/60 Hz

Net Weight (KG)/ Gross Weight

140KG / 168KG

Machine Dimension

1050*800*1200mm (L*W*H)

3d fiber laser marking machine samples-Suntop
