1500W Metal Laser Cleaning Machine

Our metal laser cleaning machines utilize advanced laser technology and are specifically designed for the efficient removal of oil, rust, and impurities from metal surfaces. They are simple to operate, non-destructive, and environmentally friendly, achieving excellent cleaning results in a short time. Widely used in manufacturing, automotive, and aerospace industries, they are the ideal metal cleaning solution.
※ Product Model: ST-FC1500H/ST-FC2000H/ST-FC3000H
※ Laser power: 1500W/2000W/3000W
※ Working area: 0-300*300mm

Availability:

Quantity:



Inquire PDF Export

Our metal laser cleaning machine utilizes advanced laser technology and is specifically designed for the efficient removal of oil, rust, and contaminants from metal surfaces. This equipment achieves non-contact cleaning by generating a high-energy laser beam, ensuring that dirt is removed without damaging the substrate, preserving the integrity of the metal surface.

This laser cleaning machine is easy to operate, equipped with an intuitive control interface, and is suitable for various industrial applications, including manufacturing, automotive, and aerospace. Its environmentally friendly characteristics eliminate the need for chemical cleaning agents, reducing the risk of environmental pollution and significantly lowering post-cleaning maintenance costs.

With its high efficiency and precise control technology, our metal laser cleaning machine greatly improves cleaning efficiency and extends equipment lifespan, making it an indispensable cleaning solution in modern industry.

Product Technical Features

1. Non-contact cleaning, precise cleaning, can achieve selective operation of precise position and precise size.

2. The handheld cleaning head is small in size and light in weight. It can be operated manually or automatically cleaned with a robot. It is especially suitable for cleaning the special-shaped surfaces of large products that are inconvenient to move.

3. Intelligent control system, clear and concise interface, easy operation, various parameters can be set to control the laser.

4. 10-meter original optical cable, universal large casters, can be moved left and right, convenient for cleaning objects that are not easy to move.

5. Built-in cold water design to avoid wire restraint, adapt to more working conditions and places, with good dust and condensation prevention effects.

6. It has multiple safety alarm functions, high safety, and ensures the absolute safety of operators at work.

7. Suntop Laser Cleaning Machine is subjected to strict tests and continuous 24-hour laser beam output before leaving our factory to ensure 100% machine stability.

Advantages of Laser Cleaning

● High-efficiency cleaning: Quickly removes oil, rust, and contaminants from metal surfaces, improving production efficiency.

● Non-destructive treatment: Utilizes non-contact laser technology, ensuring the integrity of the metal surface without damaging the substrate.

● Environmentally friendly: Eliminates the need for chemical cleaning agents, reducing environmental pollution and health risks, and meeting environmental protection requirements.

● Easy to operate: Equipped with an intuitive control interface, it is easy to operate and suitable for users of all technical levels.

● Low maintenance costs: Laser cleaning equipment is simple to maintain, with low long-term operating costs, improving economic efficiency.

● Wide range of applications: Widely used in manufacturing, automotive, aerospace, mold making, and other industries, flexibly meeting diverse needs.

FAQ

1. How can i place an order?

Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time.

For further discussion, it is better to contact us with WhatsApp / WeChat / email / phone, in case of any delays.

2. What kind of display we provide?

We have laser marking machine / laser welding machine / laser cutting machine / laser cleaning / CO2 laser cutting and engraving machine / laser accessories for you choose.

3. How about the warranty?

We have 2 years warranty and lifelong maintenance.

4. What is your terms of delivery?

We accept EXW, FOB, CFR, CIF, DDU, DDP, etc. You can choose the one which is the most convenient or cost effective for you.

5. How efficient is laser cleaning?

Laser cleaning is extremely efficient, quickly removing contaminants from metal surfaces. In most cases, the cleaning speed is far higher than traditional cleaning methods, significantly improving production efficiency.

6. Is professional training required to operate a metal laser cleaning machine?

While professional operation training is recommended, our metal laser cleaning machine is equipped with a user-friendly interface, allowing beginners to quickly learn how to use it.

7. Will laser cleaning damage metal surfaces?

No! The metal laser cleaning machine uses non-contact laser technology, allowing for precise control of laser power to ensure no damage to the metal surface during the cleaning process.

8. How environmentally friendly is laser cleaning?

Metal laser cleaning does not require the use of chemical cleaning agents, thus eliminating chemical pollution to the environment, making it an environmentally friendly and sustainable cleaning solution.

9. What are the equipment maintenance requirements?

Maintenance of the metal laser cleaning machine is relatively simple, mainly including regularly checking the laser, cleaning the lenses and lenticules to ensure the equipment operates in optimal condition. Regular maintenance is recommended to extend the equipment's lifespan.

10. Can it perform batch cleaning?

Yes, metal laser cleaning machines are ideal for batch production, capable of completing the cleaning of multiple workpieces in a short time, thus improving overall production efficiency.

Product Details

Cheapest Laser Cleaning Machine Famous Fiber Laser Generator-Suntop

Famous fiber laser generator

We use the customized 45um core diameter cleaning version fiber lasers with high photoelectric conversion, guaranteed laser power for better cleaning results, and a 100,000 hour, maintenance-free life.

Interactive touch screen control system

Advanced resistive touch screen with higher sensitivity and intelligent control, supports multiple languages (English, Spanish, German, Italian, French, Russian, Turkish, etc.)

Cheapest Laser Cleaning Machine Interactive touch screen control system-Suntop

Cheapest Laser Cleaning Machine Laser cleaning head-Suntop

Laser cleaning head

The Laser cleaning head is ergonomically designed to be small, comfortable to hold and easy to control and operate. The handheld head is easy to hold and can be used for long periods of time and can be operated at any angle, making cleaning more convenient and flexible.

Industrial water chiller

The industrial water cooler ensures heat dissipation of the core optical path components, double circulation water cooling for better cooling of the laser source and cleaning head, temperature control sensor using imported brands. It can also extend the service life of the laser cleaner.

Cheapest Laser Cleaning Machine Industrial water chiller-Suntop

Cheapest Laser Cleaning Machine Cleaning connection fiber-Suntop

Cleaning connection fiber

The cable distance from the laser cleaning head to the machine is 10 meters, and there is no need to move the machine when laser welding the workpiece.

Wide range of applications

Large cleaning area, high efficiency, up to 300*300mm.

Cheapest Laser Cleaning Machine Wide range of applications-Suntop

Main Configuration

Handheld Cleaning Head

Cheapest Laser Cleaning Machine Handheld Cleaning Head-Suntop

Features:

● High cleaning cleanliness, big welding width up to 300mm

● Precise positioning and cleaning, weight only 0.7KG, easy to hand it.

● Non-contact material when cleaning that can protect the material.

● Effectively remove micron-sized particles.

● Environment friendly, no consumables.

Factory Preset Cleaning Parameters

Cheapest Laser Cleaning Machine Factory Preset Cleaning Parameters-Suntop

Features:

● Simple preset selection ensures consistent high-quality laser cleaning results.

● Operators can instantly switch between different presets to facilitate the cleaning of multiple materials.

● Advanced operators can make custom presets, and save them for future use, and novice operators can use them to produce the same results.

● Novice operators need less training to get started, reducing labor costs while maintaining cleaning quality.

Operator Safety Features

Cheapest Laser Cleaning Machine Operator Safety Features-Suntop

Features:

● Key switch control to protect the system from unauthorized cleaning operations.

● The emergency stop button can ensure that the machine can be shut down immediately when there is a problem.

● The safety interlock device verifies the integrity of laser delivery to the cleaning gun.

● Laser triggering requires 2 steps of operation to ensure the safety of cleaning operations.

- Knob safety lock，open when in use, not afraid of misoperation

- Single button to start laser, double-click the button to start laser, two modes can be selected

● If anyone other than the operator accidentally enters the cleaning area, the door switch interlock circuit shuts off the laser.

Power	Material	Cleaning speed	Effective beam/cleaning range	Depth of cleaning	Cleaning efficiency (cubic/H)
1500W	Floating embroidery	50mm/S	150mm	20um	15
	Paint	50mm/S	150mm	100um	6
	Rusting	50mm/S	150mm	120um	4
2000W	Floating embroidery	50mm/S	300mm	20um	20
	Paint	50mm/S	300mm	100um	8
	Rusting	50mm/S	300mm	120um	5
3000W	Floating embroidery	50mm/S	300mm	20um	30
	Paint	50mm/S	300mm	100um	14
	Rusting	50mm/S	300mm	120um	9

Model	ST-FC1500H	ST-FC2000H	ST-FC3000H
Power	1500W	2000W	3000W
Power consumption	3000W	4500W	6000W
Max. cleaning width	170*170mm	250*250mm	300*300mm
Laser wavelength	1064nm
Operation mode	Handheld
Power adjustment range (%)	10-100 (Gradient adjustable)
Cleaning head weight	0.7Kg
Delivery cable length	10M (can be customized)
Input power	220V±10% 50-60HZ
Cooling system	Water Cooled with automatic pumping function
Machine weight	140KG	220KG	220KG
Machine size	9357201248mm	15008801160mm

Power	Material	Cleaning speed	Effective beam/cleaning range	Depth of cleaning	Cleaning efficiency (cubic/H)
1500W	Floating embroidery	50mm/S	150mm	20um	15
	Paint	50mm/S	150mm	100um	6
	Rusting	50mm/S	150mm	120um	4
2000W	Floating embroidery	50mm/S	300mm	20um	20
	Paint	50mm/S	300mm	100um	8
	Rusting	50mm/S	300mm	120um	5
3000W	Floating embroidery	50mm/S	300mm	20um	30
	Paint	50mm/S	300mm	100um	14
	Rusting	50mm/S	300mm	120um	9

Model	ST-FC1500H	ST-FC2000H	ST-FC3000H
Power	1500W	2000W	3000W
Power consumption	3000W	4500W	6000W
Max. cleaning width	170*170mm	250*250mm	300*300mm
Laser wavelength	1064nm
Operation mode	Handheld
Power adjustment range (%)	10-100 (Gradient adjustable)
Cleaning head weight	0.7Kg
Delivery cable length	10M (can be customized)
Input power	220V±10% 50-60HZ
Cooling system	Water Cooled with automatic pumping function
Machine weight	140KG	220KG	220KG
Machine size	9357201248mm	15008801160mm
