Marking Laser Machine Price

Portable fiber laser marking machine is a kind of laser equipment that can be lightly carried, featuring high flexibility and easy operation. These marking machines are usually designed to be small and lightweight, easy to move and carry, suitable for a variety of temporary or on-site marking needs.
Product Model: ST-FL20B/ST-FL30B/ST-FL50B/ST-FL100B
Laser power: 20W/30W/50W/100W (optional)
Working area: 110*110mm-600*600mm
Availability:
Quantity:

Details        Product Parameters        Samples       Video

marking laser machine price features-Suntop


Features of marking laser machine price

● The laser has a long service life and can be used for 100,000 hours without problems.

● The equipment adopts air-cooling technology and does not require the support of a water-cooling system.

● High beam quality, small spot size, narrow marking line width, more suitable for fine marking.

● Electro-optical conversion efficiency can reach more than 30%, energy saving and power saving.

● Adopt red light positioning system, convenient positioning, high positioning accuracy.

● The machine can be equipped with other optional accessories according to the actual product laser marking needs of customers, such as rotary device, 2D/3D worktable, pen rotary table and other fixtures.


Details of marking laser machine price

1. Laser source

Using imported pulsed fiber laser, its output laser mode is good and its service life is long.

2. Galvanometer scanning system

The high-speed digital galvanometer scanning head has good running stability and high positioning accuracy, and can realize high-speed marking with high precision.

3. Focusing system

Focuses parallel laser beams on a single point. The f-theta lens is mainly used, and the fiber laser beam is focused to the surface of the workpiece through the lens, and the energy is sufficient.

4. Computer control system

It is the control and command center of the entire laser marking machine, and it is also the carrier of software installation to complete the marking process on the workpiece.


marking laser machine price details-Suntop


Advantages of marking laser machine price

● Compact and lightweight: small in size and light in weight, easy to carry and move, and can flexibly cope with various temporary or on-site marking tasks.

●Easy to operate: Equipped with a simple control interface and operating software, the operation is convenient and fast, without complicated settings.

Efficient and convenient: quick start, plug and play, fast processing speed, suitable for small batch production or on-site marking needs.

● High-quality marking: With high precision and clarity, it can achieve high-quality marking effects.

● Low energy consumption: Laser technology itself has low energy consumption, and portable fiber laser marking machines are energy-saving and environmentally friendly.

● Stable and reliable: Using high-quality optical components and stable light source, the work is stable and reliable.


Application materials of marking laser machine price

Suitable for working with most metal marking applications such as Gold, Silver, Stainless Steel, Brass, Aluminium, Steel, Iron Titanium etc, and can also mark on many nonmetal materials,such as ABS, Nylon, PES, PVC etc.


Application industry of marking laser machine price

Widely applying for electronics, jewelry, automobiles, communication products, phone keys, plastic translucent keys, jewelry products, key chain, electronic components, integrated circuits (IC), electrical appliances, buckles cookware, stainless steel products and other industries.


Parameters of marking laser machine price

Model

ST-FL20B/ST-FL30B/ST-FL50B/ST-FL100B

Laser power

20W/30W/50W/100W (optional)

Marking area

110*110mm-600*600mm (depend on the actual laser   power)

Laser wavelength

1064nm

Working accuracy

±0.002mm

Marking Depth

0-0.5mm

Minimum font for marking

0.15mm

Minimum character

0.2mm

Marking speed

0-7000mm/s

Operating system

Win7 and Win10/32 bit and 64 bit

Laser source

MAX Brand(Raycus can be choose)

Repetition frequency

20-100KHz

Cooling mode

Air Cooling

Graphic format supported

AI, PLT, DXF, BMP, DST, DWG, DXP

Environmental requirements

Temperature: 10-35℃, Humidity: 5-75%

Working voltage

220V±10% 50/60 Hz

Applicable material

All metal (Stainless steel, Carbon steel,   Brass,etc.) and some plastic(ABS, PVC,PES, ETC.)

Optional Accessories to Purchase

D80 Rotating Shaft/ D57 Small Chuck/2D Table (X.Y   direction)/ Cutting Fixture

Net weight/gross weight (KG)

120KG / 150KG

Machine dimension

860*760*1130mm (L*W*H)



marking laser machine price samples-Suntop
