Fibre Laser Marking Machine Price

The 2.5D laser marking machine has the characteristics and advantages of high marking accuracy, fast marking speed, adaptability to multiple materials, flexibility and creativity, high energy consumption ratio, and easy operation and maintenance. It is widely used in various fields, such as electronics, manufacturing, handicrafts and other marking needs, providing efficient, accurate and reliable marking solutions.
Product Model: ST-FL20P-2.5D/ST-FL30P-2.5D/ST-FL50P-2.5D/ST-FL100P-2.5D
Laser power: 20W/30W/50W/70W/100W
Working area:110*110mm/150*150mm/200*200mm/300*300mm
Availability:
Quantity:

Details        Product Parameters        Samples       Video

fibre laser marking machine price features-Suntop


Features of fibre laser marking machine price

1. Adopting imported scanning system and scanning head, automatic focusing, no need to adjust manually, more convenient work.

2. Adopt electric column (z-axis electric column), with the change of engraving depth, z-axis will be fine-tuned to the following depth, so as to realise the precision micro-machining such as relief engraving and small-size micro-hole processing. Processing field.

3. Adopting red light positioning system, easy positioning and high positioning accuracy.

4. High speed focusing scanning system with short pulse, high peak power and high pulse repetition frequency. Working efficiency is 20% higher than similar models.

5. Small size, easy to use, easy to carry, space saving, no consumables, plug and play design.

6. Suntop fibre laser marking machine has passed strict aging test before leaving the factory, 24 hours continuous output of laser beam to ensure 100% stability of the machine.


Details of fibre laser marking machine price

1. Laser source

Suntop customised pulse MAX. Lasers with wider adjustable pulse widths for different quality marking results.

2. High quality vibration lens

Variable focal length, precise control of the focus position, to ensure the focus size and spot quality, to achieve the engraving of irregular products.

3.Motorised column (z-axis motorised)

With the change of engraving depth, the z-axis will fine-tune the depth underneath to achieve precise micromachining.

4.Air-cooled

Built-in air cooling design for better heat dissipation.


fibre laser marking machine price details-Suntop


Advantages of fibre laser marking machine price

● High laser marking accuracy: Laser beam is used for marking, which has very high marking accuracy. It can achieve fine marks and precise engravings, and is suitable for marking tasks that require high precision.

● Fast marking speed: With high-speed marking capability, it can achieve fast and efficient production speed. The high energy density and fast response speed of the laser beam make the marking process fast and accurate, suitable for high-volume and high-volume marking needs.

● Multi -material adaptability: suitable for marking for multiple materials, including metal and plastic. The characteristic of laser beam is that it can penetrate or mark surfaces, adapting to the marking needs of different materials.

● Flexibility and creativity: have flexible operation and creative design ability. Users can perform notching, engraving, laser or marking operations as needed to achieve marking requirements of different shapes and patterns.

● High -efficiency energy consumption ratio: It has high energy utilization efficiency. Compared with traditional marking methods, its energy consumption is lower. This not only saves energy, but also reduces operating costs.

● Simple operation and maintenance: have the characteristics of easy operation and maintenance. The operating interface is intuitive and clear, and users can get started and operate quickly. At the same time, maintenance and maintenance are relatively simple, reducing the stop time and cost.


Application materials of fibre laser marking machine price

Suitable for working with most metal marking applications such as Gold, Silver, Stainless Steel, Brass, Aluminium, Steel, Iron Titanium etc, and can also mark on many nonmetal materials,such as ABS, Nylon, PES, PVC etc.


Application industry of fibre laser marking machine price

Metals, alloy, oxide, ABS, epoxy resin, printing ink, etc, which are widely applying for electronics, jewelry, automobiles, communication products, phone keys, plastic translucent keys, jewelry products, key chain, electronic components, integrated circuits (IC), electrical appliances, buckles cookware, stainless steel products and other industries.


Parameters of fibre laser marking machine price

Laser Power

20W

30W

50W

100W

Model

ST-FL20P-2.5D

ST-FL30P-2.5D

ST-FL50P-2.5D

ST-FL100P-2.5D

Max Marking   Range

110*110mm    /150*150mm

200*200mm

300*300mm

300*300mm

Depth of Single   Marking

0.01mm

0.03mm

0.06mm

0.08mm

Same pattern   marking efficiency

10s

7 s

4s

2s

Whole Machine   Power

600W/h

800W/h

1000W/h

12000W/h

Laser Type

Fiber Laser

Laser Source

MAX Brand (Raycus can choose )

Control   Software

EZCAD

Cooling Mode

Air Cooling

Working   Accuracy

±0.002MM

Marking Speed

0-7000mm/s

Repetition   Frequency

20-100KHz

Laser   Wavelength

1064nm

Minimum Font   for Marking

0.15mm

Working Voltage

220V±10%    50/60 Hz

Graphic Format   Supported

AI, PLT, DXF,   BMP, DST, DWG, DXP

Applicable   Material

All metal   (Stainless steel, Carbon steel, Brass,etc.) and some plastic(ABS, PVC,PES,   ETC.)

Optional   Accessories to Purchase

D80 Rotating   Shaft/ D57 Small Chuck/2D Table (X.Y direction)/ Cutting Fixture

Net Weight   (KG)/ Gross Weight

38KG / 50KG

Machine   Dimension

420*300*550mm   (L*W*H)



fibre laser marking machine price samples-Suntop
